??Superior quality??Made of solid and weather resistant steel and powder coated black surface for great durability.This winch solenoid contactor replacement come with shatterproof sealed and corrosion resistant case.
??Easy to install??Pre-cutting mounting bracket for easy installation into control box,The installation procedure included states clearly how to install. It is easy and just follow the instruction.The two wires (Green and Black) go to the switch that controls In and Out on a winch. brown and red go to battery,blue and yellow go to winch.
??Specification??Voltage: 12V; Capacity:1500-5000lbs; The Stud is 1/4?? ;/ Universal For ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application.
??Note??It is designed to handle intermittent current loads of 250 amps for up to 10 seconds, requiring a 20-30 second cooling time between cycles.
??Applications??12V 250A Winch Solenoid Relay Contactor for all 12Vsolenoid winches,including ATV’s,UTV’s,SUV’s,Jeep’s,4×4 vehicles, and 12V Trailer ect.
For the Following Winches:

KFI: ST17, S2000, A2500, A3000, U4500, U4500w, SE25, SE35, SE45

WARN: A2000, A2500, U2500, 1.5ci, 2.5ci, 2.5ce, 3.0ci, 3.0ce, 3.0s

WARN: RT15, RT25, RT30, XT15, XT25, XT30

WARN: RT40, XT40

WARN: Vantage 2000-3000lbs, Provantage 2500-3500lbs

WARN: Vantage 4000lbs, Provantage 4500lbs

RAMSEY : ATV2500, ATV3000

SUPERWINCH : Terra25, Terra35, Terra 45, LT2000, LT2500, LT300

MILE MARKER : PE2.5, PE 3.5, VMX2.5, PE2000, PE3000, PE2500, PE3500

MASTER LOCK : 1500lbs #2955AT

CYCLE COUNTRY : Work Power 1500 and 2500, Powermax 2500 and 3500

BADLAND : 2000lb #68146

BADLAND : 3000lb #68145, 5000lb #68144

CHAMPION : C10013, C10014, C10018, 10020, 10024, 12053, 12503 13501(requires rollers), 14061

CHAMPION : 14501, 14551, 14552, 40252 (4500lbs) (Requires purchase of correct Roller Fairlead Bracket KFI #100695)

CHAMPION : 10028, 10032, 12001, 12002, 13001, 20049, 20051, 20249, 30045, 30145

CHAMPION: 14001 and 14061

KEEPER CORP. TRAKKER : KT2500, KT3000, KT2500C, KT3000C, KT4000, KT4000C , KT2000

SMITTYBILT : XRC 2.0

SMITTYBILT : XRC 3.0

XGEAR: X3000, X4000

VENOM: 2000, 2500, 3000, 3500, 4000, 4500, 5000 (Hardcore Series)

Designed for Handle Intermittent Current Loads of 250 Amp
Designed for Handle Intermittent Current Loads of 250 Amp
Voltage: 12V; Capacity:1500-5000lbs; The Stud is 1/4?? ;/ Universal For ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application.
