ATV Solenoid

HIGH QUALITY : IP 67 rated waterproof sealed and corrosion resistant case, made of solid and weather resistant steel and powder coated black surface for maximum strength and durability, best Replacement for ATV Winch Solenoid Relay Contactor Switch 12V 250AMP.
WIDELY APPLICATION : Replacement Contactor for KFI,WARN,RAMSEY,SUPERWINCH,MILE MARKER,MASTER LOCK,CYCLE COUNTRY,CHAMPION,SMITTYBILT etc.Models.Works with most brands of ATV/UTV winches. Compatible with 2000-5000 lbs winch (series wound and permanent magnet) DC.
EASY INSTALLATION : The installation in the package shows clearly how to install it. It is easy and just follow the instruction. Bule to winch positive, Yellow to winch negative, Red to battery positive, Black to battery negative, green cable to switch green, black cable to switch black.
TECHNICAL DETAILS : Working load: 250A, Operating voltage: 12V, Capacity: 2000lb-5000lb, 0ur winch contactor works on most 12V winches rated 2000lb to 5000lb, for ATV Motorcycle Boat Car Truck side by side 4X4.
LIFETIME WARRANTY : We provide lifetime warranty. If you have any questions about the winch relay, pls contact our customer service, we will help you to solve it.
Product description
This winch solenoid relay could be applicable for Winch Motors, Snow Plow Spreader Motors, Windlasses, Hydraulic Pump Motors Other Reversible Motors, etc.It could be used with 12v winches rated 2000-5000lbs.
Fit for the following models:
for KFI: ST17, S2000, A2500, A3000, U4500, U4500w, SE25, SE35, SE45
for WARN: A2000, A2500, U2500, 1.5ci, 2.5ci, 2.5ce, 3.0ci, 3.0ce, 3.0s
for WARN: RT15, RT25, RT30, XT15, XT25, XT30
for WARN: RT40, XT40
for WARN: Vantage 2000-3000lbs, Provantage 2500-3500lbs
for WARN: Vantage 4000lbs, Provantage 4500lbs
for RAMSEY : ATV2500, ATV3000
for SUPERWINCH : Terra25, Terra35, Terra 45, LT2000, LT2500, LT3000
for MILE MARKER : PE2.5, PE 3.5, VMX2.5, PE2000, PE3000, PE2500, PE3500
for CYCLE COUNTRY : Work Power 1500 and 2500, Powermax 2500 and 3500
for BADLAND : 2000lb #68146
for BADLAND : 3000lb #68145, 5000lb #68144
for CHAMPION : C10013, C10014, C10018, 10020, 10024, 12053, 12503, 13501(requires rollers), 14061
for CHAMPION : 14501, 14551, 14552, 40252 (4500lbs) (Requires purchase of correct Roller Fairlead Bracket KFI #100695)
for CHAMPION : 10028, 10032, 12001, 12002, 13001, 20049, 20051, 20249, 30045, 30145
for CHAMPION: 14001 and 14061 , KT4000C , KT2000
for SMITTYBILT : XRC 2.0
SMITTYBILT : XRC 3.0
for XGEAR: X3000, X4000
for VENOM: 2000, 2500, 3000, 3500, 4000, 4500, 5000 (Hardcore Series)
Details:
Voltage – 12V
Power C 250A
Package includes:
1 x Winch Solenoid Relay Contactor
6 x Protecting Caps
Warranty:
Lifetime warranty and customer service
