This exceptional electric winch has over 3500 pounds provides a 1.1 horsepower 210 Amp 12V DC permanent magnet motor, 153:1 single-stage planetary gear system with 3.2 feet per minute full load line speed, 13 feet per minute no load line speed which drives a powerful pulling
Waterproof IP65 powder coated surface for corrosion resistance, could be used even on extremly weather normally, with the durable 3/16 inch x 50 feet synthetic winch rope of high tensile strength that is enough to meet the needs of any outdoor towing jobs
Each lead is connected to the other end of the corresponding lead, so that it is not easy to be confused, it’s very convenient and quickly of connecting; 12.9 inches shorter red lead and 13.3 inches shorter black lead connected to the motor; 56 inches longer red lead and 68.7 inches longer black lead connected to the battery ( All leads: 9 Gauge )
The winch will include a 7.2 x 5.1 inches (L x W) universal mounting plate to for mounting on the rear of the machine,
