4500Lbs 12 Volts Electric Winch, Winch for ATV/UTV/Boat, 4500Lbs /2041kg Electric Winch Kit, with 15m/49ft Winch Synthetic Rope, Towing Off-Road Electric Winch Recovery kit (4500Lbs Black H)
S Series 4500lbs ATV Synthetic Rope Winch,It has strong pulling force and is suitable for most ATV,UTV and Boat Trailer. No Matter what kind of road conditions you meet, it will always be your indispensable assistant.
12V DC 1.3HP/1.0kw Copper Wire Permanent Magnet Motor,high strength,low loss,be used more efficiently.When the permanent magnet motor starts, the current increases gradually but does not exceed the rated current. Without current shock, the service life can be extended and the electric machine can work under reasonable load.Always stay safe.
The precise 3-stage planetary gear and the gear speed ratio of 166:1 give the winch a strong traction, which can smooth you out of danger.When the winch is No load, the line speed is 19.8ft/min and the motor current is 11AMP; when the load is 4500lbs, the line speed is 3.0ft/min and the motor current is 300AMP
It is equipped with two wireless remote controls and one wired remote control, which can support your use of the winch under different conditions. The range of the wireless remote control is 10M. The remote control uses a ground wave system that will not be affected by the signal, allowing you to be able to do it in the wild
winch has a 1 year product warranty and lifetime product technical support. If you have any product questions, please do not hesitate to contact us, we will answer your questions within 24 hours. Please note that the winch is used for pulling, please do not use it for lifting.
H Series 4500lbs ATV Winch With Synthetic Rope
Rated Line Pulls:4500 Ibs(2045kg)
SKU:H-4500-N (S Series)
Gear Reduction Ratio: 166:1
Control:Handlebar Mounted Mini-Rocker Switch and Wireless Remote Control
Gear Trian:3-Stage Planetary
Permanent Magnet Motor Motor: 1.3 hp/1.0 kW(DC 12V)
Overall Dimensions: 12.8″(L) 4.6″(W) 4.8″(H)
Drum Size: 1.9″(D)x3.3″(L)
Cable: 7/32″(D)x50′(L);5.5mm(D)x15m(L)
Weight: 28.5 Pounds
4500lbs UTVATV Winch,12V Electric Winch with Cable Wireless Winch Kit for SUV
Power Cord Connection Diagram
Connect one terminal (marked M+ ) of contactor to terminal positive (+) of the motor with red cable
Connect one terminal (marked M- ) of contactor to terminal negative (-) of the motor with black cable
Connect one terminal (marked B+ ) of contactor to terminal positive (+) of the battery with red cable
Connect one terminal (marked B- ) of contactor to terminal negative (-) of the battery with black cable
Note
Always Wear Eye Protection And Heavy Gloves When Operating The Winch.
Always Keep Body, Hair, Clothing And Jewelry Clear Of The Winch Cable, Fairlead And Hook When Operating Winch.
Always Keep The Area Around The Vehicle, Winch, Winch Cable And Load Clear Of People (Especially Children) And Distractions While
Always Turn The Vehicle Ignition Power Off When It And The Winch Are Not Being Used.
Always Be Sure That At Least Five Full Turns Of Winch Cable Are Wrapped Around The Winch Drum At All Times. The Friction Provided By
This Wrapped Cable Allows The Drum To Pull On The Winch Cable And Move The Load.
Never Attempt To Winch Loads That Weigh More Than The Winch s Rated Capacity.
