UNIQUE 8 GANG DESIGN — Operating voltage: 12-24V; Max power rating: 1,200 Watts. This powerful switch panel can help you to control 8 sets of LED light or accessories just from one convenient place at the same time. Featuring the high sensitivity, stability and strong anti-interference ability, you can customize your own switch panel with 50pcs self-adhesive labels. It will be the best way to clean up all wiring harness and control everything by adding just one panel on your vehicle.
UNIVERSAL FITMENT — Adopting the NEW IBGT (Insulated Gate Bipolar Transistor) technology instead of others’ bulky relay design, our universal switch control relay system is space saving and perfect fit for all 12V/24V DC power vehicles such as Car, Truck, off-road, ATV, UTV, SUV, RZR, Boat, Marine, Pickup, Polaris, Yachts and Caravans etc.
EASY & QUICK INSTALLATION — Never frustrating wiring connections. Different color wires are wrapped in a such compact and elegant retail box, plug & play wiring harness make the installation need only 1 hour. Two kinds of mounting ways for you to choose, you can install it in any positions you like. No need to cut a big hole on your vehicle.
SAFETY FIRST DESIGN — With an integrated overload protection system and resettable 100 Amp circuit breaker, it will automatic disconnect when the working temperature is too high. Reverse polarity protection, over-voltage protection and over-current protection, providing all your connected LED lights & accessories work safely.
ALL IN ONE — Package contents everything you need for installation and use. No need to buy any other extra parts. 8 Gang Switch Panel Pods + 50pcs Self-Adhesive Labels + 3 Sets of Mounting Bracket + Switch Control Box + Screw Tapes + Strapping Tapes + Wiring Harness + UPGRADED Installation Instruction. 2 years warranty and 24 hours excellent after-sales service!
Choosing the right Switch Panel can greatly improve safety and your enjoyment of driving at night. DJI 4X4 has now developed a new range of 8 Gang Switch Panel using the latest technology to control everything with only one panel. FEATURES -Power up to 8 lights & accessories from one place and at the same time. -You can customize your unique personal switch panel according to certain needs. -Safety first come with circuit breaker over-voltage protection over-current protection. -With 2 sets mounting bracket it can be installed in anywhere you like. -Easy Plug-N-Play Install and Wire Management. SPECIFICATIONS – Panel Size: 4.5*2.6*0.6 inch – Circuit Box Size: 7.5*1.3*4.1 inch – Panel Material: High quality ABS – Circuit Box Material: Die-case aluminum – Input Voltage: 12V / 24V DC – Maximum Power: 600W at 12V / 1200W at 24V – Maximum Current: 60A – Operating Temperature: – 40 C ~ + 150 C – Maximum Instantaneous Current: 100A How to connect the red and white cables 1. Connect the red cable to the width lamp. If you want to light up the LED lamps before the car start-up please connect the recommended because the higher the power is the more power of the battery will be consumed. 2. Connect the white cable to a momentary push button to adjust through three different brightness levels of the switch panel. If you just want to have the most brightness switch panel you can disconnect it. What is in the box: 1 x 8 Gang Switch Panel Screen 1 x Circuit Control Box 50 x Self-Adhesive Label 10 x Strapping Tapes 3 Sets of Mounting Bracket Necessary screw sets & wires Once you have completed the installation enjoy your pride and joy as soon as possible. Have fun and be safe.
