ATV Solenoid

: Solid heavy duty construction, black powder coating, shockproof, corrosion-resistant, sealed, durable.
: 12V 500A rated for use with most brands of 8000lbs-15000lbs winches. Compatible with wireless remote systems.
: suitable with most brands of 12v 8000lbs-15000lbs winches, for 4WD vehicles, ATV, UTV, SUV, etc.
: Pre-cutting mounting bracket for easy installation into control box.
: We provide one-year limited warranty. If you have any problem during the purchase period, please feel free to contact us and we will provide the most professional and timely service for you.
Product description
Specifications:
Coil Rated Voltage: 6-110V DC
Operating Voltage: 12V DC
Operating Wattage: 15W
Contact Circuit Voltage: 80V DC
Loading Current: Max. 250V AC 500A
Frequency: 10Hz-200Hz
Acceleration: 3.5g
Speed: 60-100 per min
Mechanical life: up to 100,000Ops
Electrical life: up to 50,000Ops
Compatibility:
Compatible with 8000lb-12000lb winch with DC 12V (series wound and permanent magnet)
Feature:
Solid heavy duty constructed
Come with shatterproof sealed and corrosion resistant case
Compatible with Wireless Remote Systems
Pre-cutting mounting bracket for easy installation into control box
Note:
Professionals install is strongly recommended to avoid trouble caused by inexperienced installer!
