PremiumQuality Replacement Part
Clutch Friction with Steel Plates and Springs / Gasket Kit
For Honda Models:
TRX250X 2009-2023
Order Includes:
5 x Clutch Friction Plate | 22201-KBW-900Width : 3.20 mm | 0.12″
Inner Diameter : 91 mm | 3.58″
Outer Diameter : 118.8 mm | 4.67″
4 x Clutch Steel Plate | 22321-HM8-A40
Width : 1.5 mm | 0.05″
Inner Diameter : 90 mm | 3.54″
Outer Diameter : 109.8 mm | 4.32″
4 x Clutch Spring | 22401-HN6-A30 Length : 39 mm | 1.53″Width : 14.1 mm | 0.55″Coil Width : 2.6 mm | 0.10″
1 x Clutch Gasket | 11394-HM8-000
**
