HOURS —- Keep track the actual running hours(TOT Hours) and the hours used per trip(TMR) of gas engine, also enable to set the initial hours for a replacement;Hours range: 0 to 999,99 hours.
RPM —- Monitor the engine current rotation speed value(RPM) to adjust the idle by various of firing patterns, Display the highest RPM(MAX RPM) hit since the engine started; RPM range: 0 to 25000 RPM.
MAINTENANCE INTERVALS—- Avaliable 6 groups of regular maintenance time for different engine parts:Change oil,Clean air filter,Clean oil filter,Valve clearance,Change spark plug,Clean spark plug discharger;Maintenance time range:5-999 hours.
INSTALLATION —- Easy to mount it on proper position by stick-on or screw-on, once wrap the signal detect wire(68.8inches, workable if shorten or extend) on the spark plug, it will begin to work right away.
OTHERS —- Built-in replaceable battery CR2032 with power insulated insert,which can be kept power-off status in transport before use; PC transparent board for display window,which get favorable waterproof desgin and prevent stronge vibration; Excellent after-sale guarantee(2 years) and technical support.
RL-HM068G Digital Tach/Hour Meter, 6 groups of maintenance time, RPM MAX RPM, Programmable engine firing patterns,User Shutdown,Waterproof Design.
Product Features:
HOURS
Keep track the actual running hours(TOT Hours) and the hours used per trip(TMR,resettable).
When total running hours exceed 999,99 hours,the timer will be restart from 0.
You can set an initial hours to continue the TOT timing,once replace an old hour meter; it is resettable in 1 hour before engine working.
Timing range from 0 to 999,99 hours with timing accuracy 0.1H/1H.
There are 6 groups of maintenance Interval timers: Change Oil,Clean Air Filter,Clean Oil Filter,Clean Spark Plug Discharger,Change Spark Plug, Valve Clearance Maintenance.
When maintenance timers arrived,display will be flashed to remind.
Maintenance interval time range is 5-999 hours,once it set as SVC OFF, that means the group of SVC timer to be shut down.
RPM
Monitor the engine current rotation speed value(RPM),Display the highest RPM(MAX RPM,resettable) hit since the engine started.
RPM range from 0 to25,000 RPM with 10 RPM resolution and refresh rate: 0.5S.
Once engine is off, the historic MAX RPM will be showed in 5S before then back to clock interface.
Once engine is off, the historic MAX RPM will be showed in 5S before then back to clock interface.
Works on gas engine: 2 stroke up to 6 cylinders,4 stroke up to 16 cylinders.
Specification
12 hours clock time display, working times recorded.
LCD screen size 0.98×0.5 inche ,it can be shut down by related buttons.
Product Dimension:2.24X1.44X0.68 inches
Easy to install, including accessoreis 3M adhesive Velcro, cable tie, Screws,Screw driver,Inductive cable,User manual.
Waterproof rate: IP67;CE,RoHS certification.
