Fitment list
2012-2013 Kawasaki Teryx4 750
2014-2023 Kawasaki Teryx4 800
2014-2023 Kawasaki Teryx 800
Specifications
Item: UTV Winch Mounting Bracket
Material: Heavy-Duty Steel
Process: Black Powder Coated
Condition:100% Brand New
Features
?̡?Wide Compatibility Winch Mount??
A Perfect Mount To Hold The Winches, which Provides mounting holes for installing and securing the winch simply and reliably.
Fit for 2012-2013 Kawasaki Teryx4 750
2014-2023 Kawasaki Teryx4 800
2014-2023 Kawasaki Teryx 800
?̡?Powerful Durability & Strength??
Made Of Heavy-Duty Steel?? Solid steel makes it high strength, and it could be more durable. So you don’t need to do frequent replacements. Black Powder Coated Surface surface technology makes it more resistant to corrosion, thus extending its life and maintaining the aesthetics of your vehicle.
?̡?Perfect Fitment & Mounting Pattern??
Through Computer-aided design and Multiple Fitment Tests to ensure the perfect fit. You could buy a suitable product the first time, which reduces your return worries.
Compatible with Most U.S. Standard Winches & Fairleads (Please check the size before purchasing)
Size:Winch Mounting Pattern:??Standard 4-Hole 3″x4 7/8″ (76mm x 124mm), ??Wide 4 Hole 3″x 6 5/8″ (76mm x 169mm), ??2-Hole 3.10″(78mm )
Fairlead Mounting Pattern: ??4 7/8″ (124mm), ??6″ (152mm)
?̡?Easy Installation & Reliable Service??
Installation can be completed within one hour by using conventional tools with its simple bolt-on design, No drilling or modification is required.
Powerful Customer Service Team could reply to you within 24 hours and provide you with a full range of satisfactory services and solve your problem.
?̡?Package list??
1 X Winch Mounting Plate
1 X Installation Instruction
Designed to work with the following winches:
KFI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2 (U45w-R2 and SE45w-R2 will NOT work on 2014-19 models)
KFI: AM-25 / AM-35 / AS-25 / AS-35
KFI: AS-50 / AS-50w
WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
WARN: RT40 / XT40
WARN: Vantage 2000-3000lb (Will NOT work with Vantage 4000 due to motor lead orientation)
WARN: ProVantage 2500-4500lbs
ProVantage 3500 and 4500 will require lead rotation.
RAMSEY: ATV2500 / ATV3000
SUPERWINCH: Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
MASTER LOCK: 1500lbs #2955AT
Requires roller fairlead with a 4.875″ bolt pattern;
CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
BADLAND: 2-Hole Winches
BADLAND: Standard Winches
BADLAND: WIDE Winches
CHAMPION: 2-Hole Winches
CHAMPION: Standard Winches
CHAMPION: WIDE Winches
KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
KEEPER CORP. TRAKKER: KT2000
Requires roller fairlead with a 4.875″ bolt pattern;
SMITTYBILT: XRC 2.0
Requires roller fairlead with a 4.875″ bolt pattern;
Listed models come with incorrect ATV roller fairleads.
SMITTYBILT: XRC 3.0 / XRC 4.0
XGEAR: X3000 / X4000
4-Hole Standard (3.00″ x 4.875″ bolt pattern)
VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
All with 3.00″ x 4.875″ bolt pattern mount-up
All with 3.00″ x 6.600″ bolt pattern mount-up
Traveller: 1078311 (1078311 Will NOT work on 2014-2015 models)
Traveller: 1078088 / 1078302
Requires roller fairlead with a 4.875″ bolt pattern;
Possibly many others with the below standard mounting patterns, call to confirm.
4-Hole (3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern)
4-Hole WIDE (3.00″ x 6.60″ bolt pattern with rollers that are 6.600″ or 6.000″ bolt pattern)
2-Hole (3.10″ with rollers that are 4.875″ bolt pattern)
QUADBOSS: RP25 / RP35
