PremiumQuality Replacement Part
Clutch Friction and Steel Plates with Gasket
For Kawasaki Models:
Ninja 650 EX650 2017-2023
Ninja 650 ABS EX650 2017-2023Z650RS ER650 ABS 2017-2023
Order Includes:
4 x Clutch Friction Plates | 13088-0566
Outer Diameter : 150 mm | 5.90″
Inner Diameter : 116 mm | 4.57″
Thickness : 3 mm | 0.11″
3 x Clutch Friction Plates | 13088-0557
Outer Diameter : 150 mm | 5.90″
Inner Diameter : 122.6 mm | 4.8″
Thickness : 3.30 mm | 0.13″
5 x Clutch Steel Plates | 13089-0021
Outer Diameter : 139 mm | 5.47″
Inner Diameter : 110 mm | 4.33″
Thickness : 2.0 mm | 0.09″
1 x Clutch Steel Plates | 13089-0038
Outer Diameter : 138.7 mm | 5.46″
Inner Diameter : 110 mm | 4.34″
Thickness : 1.6 mm | 0.06″
1 x Clutch Steel Plates | 13089-0039
Outer Diameter : 138 mm | 5.43″
Inner Diameter : 110 mm | 4.33″
Thickness : 2.0 mm | 0.09″
1 x Clutch Steel Plates | 13089-0039
Outer Diameter : 138 mm | 5.43″
Inner Diameter : 110 mm | 4.33″
Thickness : 2.0 mm | 0.09″
1 x Clutch Steel Plates | 13089-0558
Outer Diameter : 138 mm | 5.4″
Inner Diameter : 130.5 mm | 4.7″
Thickness : 1.9 mm | 0.07″
1 x Gasket | 11061-0164
**
