Feature:
1. The functional fuel pump is the most basic component in the engine fuel supply system. It is responsible for pumping fuel out of the fuel tank during the working process of the engine, and continuously delivering it to the engine through the fuel supply pipeline at a certain pressure. The high-pressure oil pump is used for secondary pressurization, and a fixed amount of fuel is provided for each cylinder in accordance with the work sequence of the engine.
2. The pump is more reliable than the pump which usually fails under normal load.
3. The performance of our pump installation is the same as your old pump.
4 No wiring or modification is required. Replace directly.Installation Precautions:
(1) Thoroughly clean the area around the fuel pump assembly device to avoid fuel contamination.
(2) Remove the fasteners that fix the fuel pump device in the fuel tank, and remove the fuel pump assembly. Be careful not to contaminate the fuel tank or leave items in the fuel tank.
(3) In order to avoid premature damage to the new pump, the contaminants in the fuel tank should be removed before installation, and a new filter should be replaced. Judgment of Common Faults of Gasoline Pump Assembly:
1 Difficulty in cold start
2 Engine stall
3 Poor acceleration and insufficient power
4 The sound of the oil pump is loud
5 The oil level indication is inaccurate
6 The vehicle shakes during drivingReplace Part Number??47-1014, 1009-0105, 1009-0105, 237471014, 983199, 24-71014Fitment:
Fit for 2008-2009 Polaris Sportsman 500 4×4
Fit for 2007-2014 Polaris Sportsman 800
Fit for 2006-2009 Polaris Sportsman X2 50 EFI
Fit for 2008 Polaris Sportsman X2 700 EFI
Fit for 2007-2009 Polaris Sportsman X2 800 EFIPackage Includes:
1 pcs Fuel Tank Pump
