Furnishing:
High quality and workmanship and painted
Incl. Locking block
Top link cat. 1
2x hydraulic connection
Delivery is completely assembled
Technical specifications:
Hydraulic connection: 3/8 ”
E: 460-670 mm
A: 50 mm
W: 60 mm
C: 30 mm
M: 62 mm
N: 44 mm
H: 19.2 mm
F: 62 mm
D: 210 mm
Hydraulic pressure max. 250 bar
Thrust: 3.5 to
Pulling force: 2.3 to
Weight about 9 kg
+
2 x hydraulic hose with plug and dust cover
Technical specifications:
Connection: 12-L bulkhead size 3 (usual coupling connector), 18-1.5 SW22 nipple + union
Hose designation Blue Flex SAE 100 3/8 R2AT DIN EN 853 2SN DN10 W.P.330
Operating pressure: 180 bar
Length: 75 cm
