Front Wheel Hub L Or R w/ Kit for Yamaha Raptor 700 700R YFM700R 2006-2013 NEWFits Following Yamaha Models:
Raptor 700 YFM700R 2006-2013
Raptor 700R YFM700R 2009-2013
Raptor 700R YFM700RSE Special Edition 2013
Raptor 700 YFM700RSP 50TH Anniversary 2006
Raptor 700 YFM700RYR GYTR Edition 2007
Raptor 700 YFM700RSE Special Edition 2008-2013
Raptor 700 YFM700RSP Special Edition 2008
Raptor 700 YFM700RSP2 Special Edition 2 2008
Part Number:Wheel Hub | 5144192
Bearing | 93306-00446-00
Bearing | 93306-20231-00
Seal | 93105-26026-00
Seal | 93102-22216-00
Bolt | 7518378
Nut | 95704-10500-00Dimensions & Measurements :
Front Wheel Hub
Inner Diameter:42mm
Inner Spline:35mm
Bolt Distance:47mm
Height:73.5mm
Bolt
Thread:3/8″-24
Width:15.6mm
Height:38mm
Nut
Outer Diameter:20mm
Inner Diameter:8.7mm
Height:10mm
Bearing 1
Inner Diameter:15mm
Outer Diameter:35mm
Height:11mm
Bearing 2
Inner Diameter:20mm
Outer Diameter:42mm
Height:12mm
Seal 1
Inner Diameter:26mm
Outer Diameter:42mm
Height:7mm
Seal 2
Inner Diameter:26mm
Outer Diameter:42mm
Height:7mmOrder Includes:
4 x Wheel Hub | 5144192
1 x Bearing | 93306-00446-00
2 x Bearing | 93306-20231-00
2 x Seal | 93105-26026-00
2 x Seal | 93102-22216-00
2 x Bolt | 7518378
4 x Seal | 93105-26026-00
**
