Intake Valve Kit for Yamaha Grizzly 125 YFM125G YFM125GH 2004 2005 2006-2013

SKU: PQF.01362 Category: Tags ,

Spread the love
Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on whatsapp
Share on telegram
Share on tumblr

Premium Quality Replacement Part
Intake Valve Kit for Yamaha Grizzly 125 YFM125G YFM125GH 2004 2005 2006-2013
For Yamaha Models:
Grizzly 125 YFM125G YFM125GH 2004-2013
Order Includes:
1 x Intake Valve: 5AP-12111-01-00
Intake Valve Length: 1.0″ | 26.0 mm
Intake Valve Diameter: 2.5″ | 64.4 mm
1 x Inner Valve Spring: 3FA-12113-00-00
Width: 0.79″ | 20.1 mm
Height: 1.20″ | 30.6 mm
Thickness: 0.10″ | 2.7 mm
1 x Valve Stem Seal: 2HX-12119-00-00
Length: 0.43″ | 11.0 mm
Width: 0.31″ | 8.0 mm
Inner Diameter: 0.19″ | 5.0 mm
Outer Diameter: 0.33″ | 8.4 mm
2 x Valve Cotter: 22F-12118-01-00
Width: 0.12 ” | 3.3 mm
Length: 0.29 ” | 7.5 mm
Height: 0.23 ” | 5.9 mm
**
