ATV Carburetor

SPECIFICATIONS
Outer Diameter of Air Filter Connection Point (excluding lip): 51 mm / 2.01 inches
Internal Dimensions / Diameter of Fuel Chamber: 14.5 mm / 0.57 inches
Distance Between Fixing Holes (inlet side, centre of eye to centre of eye): 38 mm / 1.5 inches
Distance Between Fixing Holes (outlet side, centre of eye to centre of eye): 38 mm / 1.5 inches
Inner Diameter of Outlet (greatest): 13 mm / 0.51 inches
Width (from inlet side to outlet side): 48 mm / 1.89 inches
Includes Throttle Cable: No
Includes Air Filter: No
Includes Inlet Manifold : No
Includes Fuel Tap: Yes
Overall Width: 51.04 mm / 2.01 inches
Overall Height: 122 mm / 4.8 inches
Diameter of Fixing Hole(s): 5 mm / 0.2 inches
Colour: Silver
Main Jet Size Outer Diameter: 6 mm / 0.24 inches
Main Jet Size Central Diameter: 3 mm / 0.12 inches
Colour: Red
Filter Element: Foam / Sponge
Outer Diameter: 60 mm / 2.36 inches
Thread Diameter: 4 mm / 0.16 inches
Overall Height: 19.5 mm / 0.77 inches
Distance Between Fixing Holes (Centre of Eye to Centre of Eye): 40 mm / 1.57 inches
