ATV Suspension

Product Description
Condition: 100% Brand New
Color: Same As Picture Show
Material: Solid Steel + Aluminium Alloy
Package Include: 1 Pair (As the picture show)
Installation Type: Eye to Eye (Please contact if you need Clevis/Straight Fork mount.)
Dimension:
Total Length: 430mm (17″)
Length of Eye to Eye Core: 400mm (15 3/4″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 7mm
Spring Width: 60mm
Working Stroke: 68mm
Spring Stiffness: 110 kg
Maximum load: 300 kg (??660 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
