ATV Suspension

Universal Fit.
gen reservoir: YES
Shock strength adjustable. Best choice for replacement, style upgrading or bike modification.
Fit on most 150cc~1006cc Sport bikes and Dirt Bikes, Go-kart and Moped Quad.(Please be noted, if your vehicle is too heavy, especially for ATV, please kindly check the Maximum load of the shocks before placing order.
Fit bikes with shocks of 400mm eye to eye distance. Please check the size details and make sure it will fit your bike before purchase. Other size please check product description for your reference.
Color:400mm Black Gold
Fitment: Universal Fit.
Work perfectly on most 150cc~750cc street bikes, Karting(Go kart), Scooters and Moped Quad (ATV) with shocks of 375mm eye to eye distance. Great choice for replacement, style upgrading and all kinds of bike modification.
**Please check below dimension before purchase.
Dimension:
Total Length: 430mm (17″)
Length of Eye to Eye Core: 400mm (15 3/4″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 7mm
Spring Width: 60mm
Working Stroke: 68mm
Spring Stiffness: 110 kg
Maximum load: 300 kg (660 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
*No fitting manual included. Recommend qualified mechanic fits or checks after the fitting of this product.
Package included:
One pair shock absorbers
Other size for shocks for your reference:
320mm(from eye to eye distance):

340mm(from eye to eye distance):

375mm(from eye to eye distance):

400mm(from eye to eye distance):
