Premium Quality Replacement Part
Primary Drive Clutch Rebuild Kit
Compatible with Polaris Models:
RZR 1000 60 Inch PS 2017-2021
RZR 1000S 60 Inch EPS Tractor 2020
RZR Trail S 1000 EPS 2022
Order Includes:
3 x Clutch Weight: 5633496
Length: 2.16 in – 55 mm
Width: 0.52 in 13.30 mm
Weight Code: 29-66
1 x Clutch Spring: 7044263
Length : 3.38 in – 86 mm
Width : 1.97 in – 50 mm
58-135
1 x EBC One Way Bearing: 1521172
Outer Diameter: 1.75 in – 44.5 mm
Inner Diameter: 1.33 in – 35 mm
Width: 1.24 in – 31.6 mm
3 x Roller: 1321622
Width: 0.54 in – 14.0 mm
Outer Diameter: 0.56 in – 14.3 mm
Inner Diameter: 0.37 in – 9.5 mm
3 x Roller Pin: 5137648
Length: 1.08 in – 27.6 mm
Width: 0.37 in – 9.5 mm
6 x Roller Washer: 5438247
Outer Diameter: 0.57 in – 14.6 mm
Inner Diameter: 0.37in – 9.6 mm
Thickness: 0.059 in – 1.5 mm
6 x Button: 5438863
Outer Diamter: 0.79 in – 20.2 mm
Width: 0.21 in – 5.5 mm
3 x Shoulder Bolt (Socket Head Cap Screw): 7512266
Length: 2.51 in – 63.8 mm
M5 x 1.0
3 x Flexloc Nut: 7541906 3235320
Inner Diameter: 0.15 in – 4 mm
Height: 0.24 in – 6.1 mm
M X 1.0
1 x DU Bushing: 3514492
Inner Diameter: 1.77 in – 45 mm
Outer Diamter: 2.0 in – 51 mm
Width: 0.98 in – 25 mm
1 x Bearing Cover: 3576510
Inner Diameter: 1.14 in – 29 mm
Outer Diamter: 1.29 in – 33 mm
Width: 0.51 in – 13 mm
1 x Spacer: 5632894
Inner Diameter: 1.26 in – 32 mm
Outer Diamter: 1.76 in – 44.8 mm
Width: 1.10 in – 28 mm
1 x Washer Limiter Spacer: 5438963
Inner Diameter: 1.12 in – 28.7 mm
Outer Diamter: 1.49 in – 38 mm
Thickness: 0.043 in – 1.1 mm
1 x Jam Nut: 7547498
Inner Diameter: 1.17 in – 29.7 mm
Width: 0.35 in – 9.0 mm
2 x Washer: 7556335
Inner Diameter: 1.33 in – 34 mm
Outer Diamter: 1.69 in – 43 mm
Thickness: 0.043 in – 1.1 mm
