ATV Brakes

Premium Quality Replacement Part
Rear & Front Brake Disc w/Bolt & Caliper for Honda Fourtrax 400 TRX400EX 2005-08For Honda Models:
Fourtrax 400EX TRX400EX 2005-2008Order Includes:
1 x Brake Disc ( Rear ) | 43251-HN1-003
4 x Bolt ( Rear ) | 90105-MK5-000 90105-MK5-010
1 x Caliper ( Rear ) | 43250-HN1-A41
2 x Brake Disc ( Front Left & Right ) | 45251-HC0-000 45251-HN1-003
6 x Bolt ( Front Left & Right ) | 90105-KL8-741 90105-MV9-003 90105-MBB-000
1 x Caliper ( Front Right ) | 45250-HM3-305 45250-HN6-006
1 x Caliper ( Front Left ) | 45150-HM3-305 45150-HN6-006Dimensions & Measurements :
Rear Brake Disc
Outer Diameter : 219.75mm | 8.65″
Mounting Hole Distance : 123.5mm | 4.86″
Width : 4mm | 0.15″
Bolt ( Rear )
Height : 24.6mm | 0.97″
Length : 7.6mm | 0.30″
Caliper ( Rear )
Mounting Hole Distance : 77mm | 3.03″
Height : 102.7mm | 4.04″
Mounting Hole Distance : 85mm | 3.34
Height : 111mm | 4.37″
Length : 100mm | 3.93″
Front Brake Disc
Outer Diameter : 173mm | 6.81″
Mounting Hole Distance : 63mm | 2.48″
Width : 3.35mm | 0.13″
Bolt ( Front )
Height : 26.2mm | 1.03″
Length : 7.9mm | 0.31″
Caliper ( Front Right )
Mounting Hole Distance : 85mm | 3.34″
Length : 111mm | 4.33″
Height : 89mm | 3.5″
Caliper ( Front Left )
Mounting Hole Distance : 85mm | 3.34″
Length : 111mm | 4.33″
Height : 89mm | 3.5″
**
