Mechanical Round Hour Meter Work Range:AC/DC 6 to 80V
Accumulating Total Running Hours TOT. Max Hours:99999.9H,Resolution 0.1 hour.
The hour meter fits in to a 2″ round hole and includes an adjustable retrainer clip so that the meter can be mounted on material up to 9/32 inch thick. Meter depth behind the panel is 1.5 inches
6-digit display,easy to read 7 mm digits;long lifetime.Warrant 2 Years.
Quartz Hour Meter for Lawn Mower Marine Boat Engine Motocross Marine Motorcycle Snowmobil ATV Boat Generators Tractor
Runleader RL-HM009 Snap IN Mechanica hour meter for DC 8-80V powered equipmet such as fork lifts, golf carts, floor care equipment, and any other battery powered equipment.
Product Function:
Timing System:
Accumulating total running hours TOT
Max Hours:99999.9H,Resolution 0.1 hour
Unique Design:
Easy installation, long lifetime
Warrant 2 Years.
Product Specification:
Display Reading:999999V with running indicator(Automatically recycle to zero)
Digit Height:7MM
Operating Voltage:6 to 80V AC 50/60hz(This meter is DC 6-80V. If you need AC 110-220V ,please kindly leave message to us)
Resolution:0.1hours
Storage and Operating:-40??C to +85??C temperature
Humidity:95% RH+32C for 2Hours
Protected from:Aiternator load dump,inductive Switching
Polarity:Positive/Negative
Case Style:Front panel mount,Other styles are available
