This is a set of new Front CV axles & wheel bearings for an Arctic Cat UTV.They fit the following 4×4 models:2009-2015 … Prowler 550 / XT 5502006-2009 … Prowler 650 / XT 6502008-2014 … Prowler XT 700 / XTX 7002011-2015 … Prowler HDX 7002009-2014 … Prowler XTZ 1000*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
High speed bearings manufactured for long life
Double lip seals made to keep grease in and dirt and water out
Inboard CV joint spline count: 24 (both)
Outboard CV joint spline count: 27 (both)
Compressed overall axle length: 695 mm and 662 mm
Replaces OE # (axles) 502-940, 1502-347, 1502-803, 1502-939, 1502-348, 1502-802, (bearings) 1402-027, 1402-809
