ATV Suspension

Its high strength rebound motion of the shock release you in harsh driving conditions.
Built- in hydraulic airbag, 24 segments adjustable soft and hard damping.
Damping spring can adjust soft and hard, high comfort, super soft.
Suitable for motorcycles with 2 piece rear shock absorbers.
We will do our best to solve any problem and provide you with the best customer services. Product Description
Name: Motorcycle rear shock absorber
Material: T6063 aluminum alloy
Process: CNC precision numerical control
Color: black
size:
Eye-to- eye core length: 320/340/360mm
Eye diameter ( with sleeve): 10 mm
Eye thickness: 21mm
Maximum tensile strength of eyes: 2, 000 Kgf
Spring width: 64mm
Spring thickness: 7mm
Working stroke: 55mm
Spring stiffness: 110 kg
Maximum load: 200 kg ( 440 lb)
Air storage: adjustable
Factory air pressure: 0. 4 Mpa
Maximum air pressure: 0. 5 Mpa
Number of pounds: 80 pounds per stick
Installation position: rear shock absorption
Installation method: straight up
