ATV Suspension

Specification:
Item Type: Pair Air Front Shocks Absorbers
Material: Solid steel and aluminium alloy
Color: Red, Gold, Silver
Eyelet to Eyelet Length: 410mm
Eye Diameter: 10mm or 10.3mm
Spring thickness: 8.2mm
Spring Width(approx): 67mm
Max Load:100kg-300kg
Size: Please check the attached picture of other size detail and the length is the eyelet to eyelet length.
Item Type: Air Rear Shocks Suspension Absorbers
Material: Solid steel and aluminium alloy
Color: Red, Gold, Silver
Eyelet to Eyelet Length: 395mm
Eye Diameter: 10mm
Spring thickness: 11mm
Max Load:100kg-300kg
Size: Please check the attached picture of other size detail and the length is the eyelet to eyelet length.
Features:
Beefed up upper and lower eyelets and caps made of aircraft grade aluminum
Heavy duty thicker gauge main springs increases the max loading to 1000lbs/pair
High quality reservoir oil seals
Pre-filled with high pressure nitrogen
Mechanical and Nitro adjustable
Constant rate springs
Air and oil dampening
Fitment:
For Honda Sportrax TRX400EX (All Years)
For Honda TRX450R (All Years)
For Honda TRX450ER (All Years)
For Yamaha YFZ450
For Yamaha Raptor 660 660R 700 700R
For Suzuki Z400 QuadSport LTZ400 ATV
Note:
Please check the size measurement chart carefully before purchasing
Please allow 1-2mm for variance due to manual measurement
Installation instruction is not included
If you have questions, please feel free to contact us, thank you!
Package Included:
1 Pair (Left & Right ) Air Front Shocks Absorbers (As the picture)
1 * Rear Air Shocks Absorbers
