ATV Suspension

Specification:
?? Item Type: Pair Air Front Shocks Absorbers + Pair Air Rear Shocks Absorbers
?? Material: Solid steel and aluminium alloy
?? Color: Red, Black Silver
Pair Air Front Shocks Absorbers
?? Eyelet to Eyelet Length: 505mm
?? Eye Diameter: 10mm or 10.3mm
?? Spring thickness: 10.4mm
?? Spring Width(approx): 85mm
?? Max Load: 100kg-300kg
Pair Air Rear Shocks Absorbers
?? Eyelet to Eyelet Length: 550mm
?? Eye Diameter: 10mm or 10.3mm
?? Spring thickness: 12mm
?? Spring Width(approx): 96mm
?? Max Load: 100kg-300kg
Size: Please check the attached picture of other size detail and the length is the eyelet to eyelet length.
Features:
?? Beefed up upper and lower eyelets and caps made of aircraft grade aluminum
?? Heavy duty thicker gauge main springs increases the max loading to 1000lbs/pair
?? High quality reservoir oil seals
?? Pre-filled with high pressure nitrogen
?? Mechanical and Nitro adjustable
?? Constant rate springs
?? Air and oil dampening
Fitment:
?? Fit For POLARIS RZR S 800 2009-2014 UTV
?? Fit For POLARIS RZR 800 2008-2014 UTV
Note:
?? Please check the size measurement chart carefully before purchasing
?? Please allow 1-2mm for variance due to manual measurement
?? Installation instruction is not included
?? If you have questions, please feel free to contact us, thank you!
Package Included:
?? 1 Pair (Left & Right ) Air Front Shocks Absorbers (As the picture)
?? 1 Pair (Left & Right ) Rear Air Shocks Absorbers (As the picture)
