ATV Suspension

Compatibility: This shock absorber is an universal part. Works great on most 150cc-750cc street bike, dirt bike, dual sport, moped quad ATV, go kart, etc.
Fits ALL quad vehicle and motorcycle with 400mm (15.75 inches) eye-to-eye length, we recommend to consult with your local dealers or measure the eye to eye length of your original shocks before purchase. Great replacement for your old shock absorbers, upgrading the exterior appearance of your vehicle.
Each shock absorbers are already filled with gen gas in factory, providing better shock absorb performance. You can adjust the air reservoir to change the shock power.
Made from high quality solid steel and aluminum alloy, very sturdy and durable. Each package contains 2 shock absorbers as picture shown.
Super fast delivery, directly ship from USA.
Fitment: Universal Fit.
Work perfectly on most 150cc~750cc street bikes, Karting(Go kart), Scooters and Moped Quad (ATV) with shocks of 375mm eye to eye distance. Great choice for replacement, style upgrading and all kinds of bike modification.
**Please check below dimension before purchase.
Dimension:
Total Length: 430mm (17″)
Length of Eye to Eye Core: 400mm (15 3/4″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 7mm
Spring Width: 60mm
Working Stroke: 68mm
Spring Stiffness: 110 kg
Maximum load: 300 kg (660 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
*No fitting manual included. Recommend qualified mechanic fits or checks after the fitting of this product.
Package included:
One pair shock absorbers
Other size for shocks for your reference:
320mm(from eye to eye distance):

340mm(from eye to eye distance):

375mm(from eye to eye distance):

400mm(from eye to eye distance):
