Wiring Harness Switch Key Coil Relay for Yamaha Raptor 700 YFM700R SE 2009-2012

SKU: XS.00495 Category: Tags ,

Spread the love

Premium Quality Replacement Part
Wiring Harness Switch Key Coil Starter RelayFor Yamaha Models:
YFM700R Raptor 2009-2012
YFM700 Raptor SE 2009-2012Order Includes:
1x Wire Harness | 1S3-82590-21-00 1S3-82590-20-00
1 x Starter Relay Solenoid | 4D3-81940-00-00 1S3-81940-00-00
1 x Ignition Coil | 3TB-82310-00-00 4DN-82320-00-00 2UJ-82310-00-00
2UJ-82320-00-00 2UJ-82310-01-00 3SX-82310-00-00
1 x Ignition Switch Key | 4SH-82510-00-00 4SH-82510-01-00Dimensions & Measurements :
Starter Relay Solenoid
Height : 41mm | 1.6″
Terminal Spacing : 18mm | 0.7″
Width : 51mm | 2.0″
Length : 47mm | 1.9″
Ignition Coil
Height : 46mm | 1.81″
Length : 92.4mm | 3.63″
Mounting Hole Distance : 75.4mm | 2.96″
Ignition Switch Key
Height : 50mm | 1.96″
Length : 38.3mm | 1.50″
Gears : 2 Shift
**
